3.3kw 48V 96V Charger for LiFePO4 Battery Pack
Product Description
- Product Description
- Product Parameters
- Detailed Photos
- Certifications
- FAQ
3.3kw 48v 96v Charger for LiFePO4 Battery Pack
| Nominal voltage | Max output current | Output Voltage range | Item no Lead acid battery | Item no Lithium Battery |
| 72V | 40A | 25~99V | HK-J-72-40 | HK-J-H99-40 |
| 96V | 32A | 33~132V | HK-J-96-32 | HK-J-H132-32 |
| 144V | 23A | 50~198V | HK-J-144-23 | HK-J-H198-23 |
| 312V | 10A | 110~440V | HK-J-312-10 | HK-J-H440-10 |
| 540V | 7A | 163~650V | HK-J-540-07 | HK-J-H650-07 |
| Basic specification | ||
| NO | Terms | Parameter |
| 3 | Input voltage range | AC90V~264V |
| 4 | Frequency | 45Hz~65Hz |
| 5 | Power factor | ≥0.99 |
| 6 | Efficiency at full loading | ≥93% |
| 7 | Mechanical impact and vibration grade | QC/T 895-2011 |
| 8 | IP grade | IP67 |
| 9 | Operation temperature | - 40ºC~85ºC |
| 10 | Storage temperature | - 40ºC~105ºC |
| 11 | Charging control | CAN or Enable |
| 12 | Protection | Output over-voltage, over-current, short-circuit, polarity reverse, input low-voltage, input over-voltage, over-temperature |
| 13 | Size | 222(length) x 109(width) x 125(height)(fan-cooled) |
| 14 | N.W. | 5.2kg |
| 15 | Cooling way | Enforce Air Cooling,Liquid-cooling |
Packing&Shipping
Lithium battery is Dangerous Good for shipment by Sea and By air and they should be shipped under regulation of UN3480. All EVL Battery are
packaged by DG plywood case and we provide UN38.3 test report and MSDS. please check shipping cost before place order, lithium battery is
Dangerous Good, the shipping cost is very different, so please check shipping cost before place orde
Company Introduction
EVL Battery Limited is a leading NCM Lithium Battery manufacturer from China and its a public company in Hongkong Stock Exchange market,
there are 4 facotry in Fujian and Guangdong. the production capacity of 4 factory is as much as 20 GWH per year. EVL Battery Limited is Number
one Lithium Battery manufacturer from China
Our Services & Strength
We provide high quality EVL Battery to client all over the world and help cleints deliver battery from China to them by sea an by air at reasonable
price. and we provide necessary technical support and warranty to you!
Q: What is the life expectancy of a Lithium battery?
A: The typical estimated life of the Lithium Iron Phosphate (LiFePO4) battery is 5-15 years or 2000 to 8000 charge cycles. One charge cycle is a period of use from fully charged, to fully discharged, and fully recharged again.Q: If I want to charge LiFePO4/Lithium Ion battery, which already has PCB, would a normal SLA controller work fine?
A: For LiFePO4 / Lithium-Ion battery, we always recommend using LiFePO4/Lithium-Ion Solar Controller. Especially if you are using the battery as UPS (back up power supply). The Lead-Acid solar controller will constantly provide pulse current to the battery. In the long run, it might damage the PCB. So the PCB won't be able to protect the battery when it should be.
Q:I am a distributor. Can I cooperate with battery warehouse for a long time?
A: Yes, Individual pricing for large scale projects and wholesale demand is available
Q: Why hasn't my ups or FedEx transportation number been updated?
A: This is normal, in countries with tariffs, our packages need to pass the customs of your country before they can be delivered to the local UPS or FedEx. Once they pass the customs and update the transportation number, you can usually receive the goods within 3-5 days.
Q: Are the cells I bought balanced?
A:we know the importance of maintaining the consistency of each cell in the battery pack, so we will match and balance all cells to ensure that the internal resistance, voltage, and capacity of cells are completely matched and balanced before delivery. This process is very necessary.
